Introducing the TW100100(AI) X-ray security inspection system, a cutting-edge solution designed to elevate security standards across diverse environments. This next-generation system seamlessly integrates intelligent detection, multi-functional capabilities, and a high-resolution display, making it ideal for transportation hubs, office buildings, large events, courts, prisons, hospitals, and various public places. Engineered with a generously sized tunnel, it ensures thorough and efficient screening of large suitcases, parcels, and extra-large backpacks. Powered by advanced material discrimination technology, it accurately classifies objects by color (3 or 6 options) and intelligently recognizes over 35 major target types, triggering automatic alarms. Experience crystal-clear, high-definition X-ray images, dynamic conveyor speed adjustment for different scenarios, and robust remote management features for real-time monitoring and data access, guaranteeing unparalleled security and operational flexibility.
ai Based
Baggage Counter
Baggage Recording
Compact Design
Energy Saving
Fingerprint Login
High Resolution Color Display
One Key Turn Off
Scan Palletized Load
Sound & Light Alarm
| Specification | Details |
|---|---|
| Tunnel Dimensions | 1000 mm (W) × 1000 mm (H) |
| System Dimensions | 3276 mm (L) × 1296 mm (W) × 1810 mm (H) |
| Conveyor Height | 300 mm |
| Conveyor Speed | 0.2 m/s, 0.3 m/s, 0.4m/s adjustable |
| Max. Conveyor Capacity | 200 kg |
| Wire Resolution | 38/40 AWG |
| Penetration (Steel) | 34/36 mm |
| Number of Generators | 1 |
| Anode Voltage / Current | 160KV |
| Cooling / Working cycle | Oil-cooling / Continuous |
| External dose rate | < 0.5 µSv/h (50mm Distance to the Housing) |
| Film Safe | Guaranteed up to ISO1600 |
| Prohibited Goods Detection | 35 Major Types, over 64 categories |
| Others | Shield Alarms, etc. |
| Cameras | 5 camera, Resolution: 1920 x 1080 |
| Sensor Type | 1/2.8" Progressive Scan CMOS |
| Video Compression Standard | H.265 / H.264 / MJPEG |
